50-200L High Efficient Extracting Concentrating Unit Machine

Basic Info Herbal extracting concentrator unit Widely applied in pharmaceutical, health food industry for extraction and concentration of the herbal, alcohol recovery and etc. The equipment is designed with advanced technology, united with extractor and outer-circulation evaporator together to...

Send Inquiry
50-200L High Efficient Extracting Concentrating Unit Machine

Basic Info

Type:Sliced Herbal Medicine MachineryFinished Dosage Form:Liquid
Precision:High PrecisionCertification:CE
Voltage:380VComputerized:Computerized
Customized:CustomizedCondition:New
Warranty:1 Year

Herbal extracting concentrator unit
Widely applied in pharmaceutical, health food industry for extraction and concentration of the herbal, alcohol recovery and etc.
The equipment is designed with advanced technology, united with extractor and outer-circulation evaporator together to proceed extracting and concentrator process at the same in this machine unit, one time production procedure until necessary ratio poultice material be extracted. Reasonable process technology, low energy consumption and great extracting productivity, short production period. It's wildly applied in pharmaceutical, health food industry for extraction and concentration of the herbal, alcohol recovery and etc.
Herbal extracting concentrator unit Feature:
1. This equipment has excellent manufacture, complete collocation, simple operation. It is consist of extracting tank, concentrated pot, storage tank for recycling liquid material, condenser, oil-water separator, filter, delivery pump, vacuum pump and so on. We have steam heating and electric heating, the user can operate it only to engage the steam or electricty.

2. This equipment collect extraction, vacuum concentration, solvent recovery together and it can realize the operation of normal temperature extraction, low temperature extraction, hot circumfluence, low temperature circumfluence, low temperature concentration and essential oil collection etc. The concentration proportion can get above to1.4 and the temperature can be controlled between 48-100°C freely, so it is espically suitable for some high heat-sensitivity material and some material is sensitive to high temperature.

3. This equipment can configure with PLC control system according to user's demand and control the parameter during the processing to enhance the production efficiency and quality.
Technical Parameter:


Type

Extracting tank capacity

Concentrator evaporating

Raw material
Supply

Concentation
Ratio

Extractiion tank platform height

L

Kg/h

Kg/h


M

RTN500/150

500

150

50-150

1.2-1.35

2.7

RTN1000/350

1000

350

140-300

1.2-1.35

3.5

RTN2000/750

2000

750

280-400

1.2-1.35

3.8

RTN3000/1000

3000

1000

400-800

1.2-1.35

4.5

RTN6000/2000

6000

2000

800-1600

1.2-1.35

5.0


Our Services
Design: Client Provide the project information and parameters, We designt he evaporator for him.
Manufacture: Manufacture the product according to the design by ourselves.
Purchase: We responsible for the raw material purchasing.
Sell: Sell client the completely machinery.
After-Service: Arrange engineer come to the site for machinery installation and commisioning.
Warranty: Product waranty 12 month.

Produce processing Progress: Discussing -- Design--Client Placed the order--Purchase raw material--Make the Processing Drawing--Arrange to the factory--Start manufacture--Pre-install in our factory--marking--Polishing--Checking--Packing--Shipping --Installation&commisioning service--after-sales service.

Packaging & Shipping
Packaging: One system machinery could be packed in the container, instrument packed in wooden case. Usually 20ft, 40OT, 40HQ.

Shipping: Usually shipped by sea, also accept by air or by car.
